TOTAL STATIONS

LAND SURVEYING EQUIPMENT & TOTAL STATION SOLUTIONS

Trimble delivers integrated and modular GNSS systems for surveyors and GIS professionals across New Zealand, offering reliable, advanced solutions tailored to local surveying and mapping needs. Leading the industry with cutting-edge technologies, Trimble provides the ProPoint GNSS engine for precise surveying in challenging NZ environments and the Trimble Inertial Platform (TIP) for accurate measurements, even with a tilted survey pole.

Talk to Sales

Trimble total stations deliver unmatched surveying precision

SCANNING TOTAL STATIONS

TOTAL STATIONS

Trimble SX12

High-accuracy total station with high-precision scanning capabilities.

Explore

ROBOTIC TOTAL STATIONS

Compare All

TOTAL STATIONS

Trimble S9 HP

Combines top field technologies with the highest level of accuracy and most advanced engineering features

Explore

TOTAL STATIONS

Trimble S9

Get smarter responses, upload files and images, and more.

Explore

TOTAL STATIONS

Trimble S7

Measure and more with a single operator.

Explore

TOTAL STATIONS

Trimble S5

Built with proven technology for remote, solo operation.

Explore

TOTAL STATION ACCESSORIES

Explore Trimble Geospatial’s full range of accessories for land surveying, construction, mapping and other geospatial applications. From durable tribrachs to practical backpacks, discover the tools that help you unlock the full capability of your Trimble equipment.

Accessories Catalogue

Frequently Asked Questions

Which Trimble total station is right for me?

It depends on how you work.

Trimble robotic and scanning total stations can be fully operated by one person and feature the highest in accuracy, range, tracking and performance options.

Trimble mechanical and Autolock® total stations are ideal for two- or three-person crews with one or two people operating the total station and another person using the rod to locate or stakeout points.

Learn more: Total Station Product Comparison

What options are available on the Trimble SX12 scanning total station?

The Trimble SX12 features 1″; angular accuracy, a Trimble VISION camera system, and the ability to scan 26,600 points per second up to 600 meters away, with a clean point cloud where range noise is just 1.5 mm at 200 m range.

The SX12 is available with or without the laser pointer; it can be added as an upgrade after initial purchase.

Regionally, the SX12 is available in two different radio models. Please contact your local distributor to learn more.

What are the main differences between robotic and Autolock® total stations?

Trimble S series total stations (S5, S7, S9 and S9 HP) are available in two versions:

Trimble robotic total stations can be fully operated by one person using a radio link to the controller and feature the highest in accuracy, range, tracking and performance options.

Trimble Autolock®, total stations can also be operated by one person for certain tasks, but are ideal for two- or three-person crews with one person operating the total station and another person using the rod to locate or stake out points.

What options are available on Trimble S Series total stations?

S series models (S5, S7, S9, S9 HP) can be ordered with a range of options including: Autolock® or robotic, angular accuracy (0.5″, 1″, 2″, 3″, or 5″), Electronic Distance Measurement (EDM) technology and an integrated Trimble VISION camera system.

Some options are only available on certain models, for example, 0.5″ angular accuracy is available only for the S9 and S9 HP models.

Review the compare tables below to see all of the options available for each model.

Compare all robotic total stations

Compare all Autolock total stations

What options are available on Trimble C Series total stations?

C series models (C3, C5, C5 HP) come standard with Trimble Autofocus technology and two onboard controllers. You can choose the angular accuracy (1″, 2″, 3″, or 5″) and Plummet type (Laser or Optical).

Trimble C3 is available with intuitive onboard software and alphanumeric keys, whereas the Trimble C5 and C5 HP are available with color touchscreen displays running Trimble Access software.

Electronic Distance Measurement (EDM) technology in the Trimble C3 and C5 have longer range, whereas the EDM technology in the C5 HP is more accurate.

Are Trimble total stations easy to maintain?

Trimble total stations are built to last and require fewer preventative maintenance check-ups than other similar products. The recommended preventative maintenance interval for Trimble C series is every year and for Trimble SX12 and S series total stations every two years.

Learn more: How Often Do Robotic Total Stations Really Need Preventative Maintenance?
